Highlights
Multi Voltage AC110V-265V, 220V, 400V
3 years warranty, 6 years design life
Prolong lamp life at least 10%
Energy-saving up to 15%-45%,
Dimmable 50%-100% continously.
Our Advantages:
1.5 years of producing experience, before that, more than 6 years of HID ballast R&D experience. -- R&D team comes from Zhejiang University which has the leading E-lighting technology in the world, ever cooperated R&D HID lightings with many famous companies.
2.600 workers, 40, 000 sqm workshop with ISO9001, ISO14001 certificates. Products are CE, UL FCC approved.
3. Top rank of waving soldering, glue potting machine, and aging equipment.
4. Whole process test strictly, at least 5 full days of aging test, do well in EMC, THD, and PF, high efficiency and waterproof, shockproof, dustproof.
5. Use Japanese components, make sure the long lifetime.
6. Honest with specifications and warranty, think highly of clients' comment, supply customized service
7. All of our ballasts are full injected of high quality white glue, not cheap black glue. This glue can keep better seal ability, heat dissipation, water proof, shock proof and better conductivity.
Multi Voltage AC110V-265V, 220V, 400V
3 years warranty, 6 years design life
Prolong lamp life at least 10%
Energy-saving up to 15%-45%,
Dimmable 50%-100% continously.
Our Advantages:
1.5 years of producing experience, before that, more than 6 years of HID ballast R&D experience. -- R&D team comes from Zhejiang University which has the leading E-lighting technology in the world, ever cooperated R&D HID lightings with many famous companies.
2.600 workers, 40, 000 sqm workshop with ISO9001, ISO14001 certificates. Products are CE, UL FCC approved.
3. Top rank of waving soldering, glue potting machine, and aging equipment.
4. Whole process test strictly, at least 5 full days of aging test, do well in EMC, THD, and PF, high efficiency and waterproof, shockproof, dustproof.
5. Use Japanese components, make sure the long lifetime.
6. Honest with specifications and warranty, think highly of clients' comment, supply customized service
7. All of our ballasts are full injected of high quality white glue, not cheap black glue. This glue can keep better seal ability, heat dissipation, water proof, shock proof and better conductivity.
| Input Voltage | 110V–240V / 50–60Hz |
| Voltage Range | 100V–265V |
| Input Current | 4 –10.5 A |
| Output power | 1000W |
| Power Factor | ≥0.98 |
| Ignite voltage | 4KV max (Cold lamp) |
| Ignite time | 2s max (Cold lamp) |
| THD | <10% |
| Environmental Temp | -30oC – +50oC |
| Enclosure Temp.Rise | 55oC |
| Low Start Current | 0.5 × Operating Current |
| Constant Output Power | 3.5% output power variation @ 15% input voltage variation |
| Full Protection | Protection for open circuit, short circuit, over temperature and over output power limit |
| Dimming | Support |
| Efficiency | 95.5% max |
| Current crest factor | <1.5 |
| Max. Lamp distance from ballast | >10m |
| Environment | Outdoor |
| Internal fan | NO |
